Qualified Hardware Platforms for Industrial Real-Time Applications on Windows
In collaboration with InoNet, Kithara presents qualified hardware platforms for demanding real-time applications on Windows. These systems are particularly suitable for applications with high requirements regarding determinism, data throughput, and computing performance — such as machine vision, sensor technology, AI, ADAS, or industrial automation.
Concepion®-jX-v4.2-U100
Compact Fanless Embedded PC with PCIe Slot and
High Performance Density Powered by Intel® Core™ Ultra CPUs
The Concepion-jX-v4.2-U100 is a powerful embedded PC featuring an Intel Core Ultra processor and a PCIe Gen 4 expansion slot for custom cards or additional hardware modules. Its fanless design and compact form factor make it robust and maintenance-free. The system is ideally suited for continuously operating point-of-sale systems requiring fast data processing and reliable 24/7 performance. USB-C and three 2.5 Gbit LAN ports enable high-speed data communication, while optional Wi-Fi, Bluetooth, GNSS, and LTE modules provide maximum deployment flexibility.
- Intel Core Ultra multi-core architecture
- Passive cooling for robust continuous operation
- High parallel processing capability for machine vision and real-time tasks
- Optional GNSS/PTP support for precise time synchronization
- Suitable for compact edge and sensor systems
Concepion®-tXf-v3-L-R680E
Compact Edge Intelligence System with Intel® Core™ i CPUs
up to 14th Generation and AI Support
The Concepion-tXf-v3-L-R680E is a compact edge intelligence system designed for high-performance applications. It supports Intel Core i CPUs up to the 14th generation and can optionally be equipped with powerful GPUs. The system optionally offers extensive communication capabilities including Wi-Fi, Bluetooth, GNSS, and LTE (5G available on request) and features a robust galvanized steel enclosure designed for 24/7 operation.
Additional features include a sophisticated cooling concept, up to 64 GB DDR5 memory, and versatile mounting options (wall mount, desktop, or 19-inch rack compatibility). With interfaces such as 2× 2.5 Gbit LAN, multiple USB ports, and DisplayPort 1.4a support, the system is ideally suited as a gateway for edge intelligence applications. It runs on Windows or Linux and offers long-term availability as well as high reliability in industrial environments.
- High performance with Intel Core i CPUs of the 12th, 13th, and 14th generations
- Optional high-performance GPU (VPU and FPGA available on request)
- Edge intelligence gateway
- Optional Wi-Fi/Bluetooth/GNSS/LTE support (5G available on request)
- Advanced cooling concept
- Robust full-industrial components for 24/7 operation
- Two additional 2.5" drive shuttles
Mayflower®-Q12W-SP5
Liquid-Cooled High-Performance Server
for AI/GPU Applications with up to 12 PCIe Slots
The Mayflower-Q12W-SP5 is a liquid-cooled high-performance server specifically designed for AI and GPU applications. The system features an industrial-grade motherboard engineered for 24/7 operation and long-term availability. It supports AMD EPYC 9004/9005/97×4 series processors, cooled via liquid cooling.
The server offers up to 12 PCIe Gen 5 slots, six of which can be flexibly configured as PCIe x16 or PCIe x8, as well as support for multi-GPU configurations, making it ideal for industrial image and video processing applications. The chassis is a 19-inch 4U rackmount enclosure featuring hybrid cooling with fans and liquid cooling for the CPU and up to five PCIe cards.
In addition, the system provides numerous interfaces including multiple LAN ports, USB ports, and VGA, as well as support for Microsoft Windows Server and Linux. With up to 4 TB DDR5 RDIMM memory capacity and a rugged design, the Mayflower-Q12W-SP5 is ideally suited for deployment in demanding industrial environments.
- AI support through multi-GPU capability and high-performance CPU
- Liquid cooling for CPU and GPU, tensor, and network cards
- Ideal for industrial image and video processing with AI support
- Up to 12 PCIe Gen 5 slots
- Robust full-industrial components for 24/7 operation
ReliaCOR 40-13
Fanless Design with 4× PoE for Machine Vision
and Real-Time Communication
The ReliaCOR 40-13 is designed for industrial applications and provides reliable operation thanks to its rugged construction and power supply design. The system is compact, energy-efficient, and suitable for installation in confined spaces; optional mounting accessories further increase its versatility. Completely fanless and without ventilation openings, it offers exceptional reliability and fault tolerance even under extreme workloads.
The ReliaCOR 40-13 is equipped with a 13th-generation Intel® Core™ i9 CPU delivering high computing performance and provides ample memory capacity through two SO-DIMM slots. It offers a comprehensive set of interfaces, including two 2.5 Gbit Ethernet ports with TSN support, eight USB 3.2 ports (10 Gbps each, ideal for cameras), and two serial ports. Thanks to its two universal expansion bays, additional interfaces and devices can be integrated (e.g. 4G/5G cellular modules, 2×10 GbE ports, 4×GbE via RJ45 or M12, optional PoE, and additional USB ports). ReliaCOR 40-13 also supports a wide range of fieldbus interfaces, including optional CAN, RS232/422/485, and isolated digital I/O.
The ReliaCOR 40-13 offers best-in-class cybersecurity. It is a market leader with IEC 62443-4-1/-4-2 SL2 certification and is also compliant with California SB-327 password legislation. Security starts at the hardware level, with full TPM 2.0 support, Secure Boot, and a continuously active physical tamper detection and logging mechanism that remains operational even when the system is disconnected from power. For the most demanding customers, production-locked system images with comprehensive hardware hardening (including interface deactivation) can be configured to further reduce the attack surface.
Eurotech's configuration management service provides a simple and efficient way to tailor the ReliaCOR 40-13 to specific project requirements. Examples include custom branding with logos and custom colors, as well as extensive adaptations such as frame grabbers, selection of internal components, and other customization options.
- Up to 6 Ethernet ports, including 4 with PoE, e.g. for GigE Vision cameras
- Passively cooled system despite powerful multi-core CPU
- High parallel processing capability, ideal for machine vision and real-time applications
- Expandable with M.2 NVMe for persistent real-time data storage
